More Speed, More Insight: Use of FFT-based EMI Test Receivers for EMI Compliance Measurements

1312 F1 coverFFT-based EMI test receivers can be used for EMI compliance measurements in accordance with Amendment 1 to 3rd Edition of CISPR 16-1-1 if this standard is referenced in the product standard. The use is motivated by reducing the scan time by several orders of magnitude and to get more insight due to the possibility of applying longer measurement times and enhanced measurement functions like spectrum in persistence mode. For precise and reproducible measurements the use of preselection filters is highly recommended.

Traditional EMI test receivers are used for measuring a signal within the IF bandwidth during the set measurement time. This results in a long scan time for the entire frequency range as the measurement time per frequency point needs to be quite long to capture intermittent emissions. FFT-based receivers measure the emitted signals in frequency segments much wider than the measurement bandwidth. The actual measurement bandwidth is achieved via a FFT filter bank and a bank of weighting detectors. This approach offers the following benefits:

  • Time needed for measurement of electromagnetic emissions is significantly reduced by approximately the number of filters used with the FFT filter bank plus the time needed by the test receiver to switch frequency. This reduces test time up to several orders of magnitude without
  • degradation of accuracy.
  • Allows application of longer measurement times, e.g. for measuring intermittent signals.
  • Makes enhanced measurement functions like spectrogram and spectrum in persistence mode applicable.

With the publication of Amendment 1 to 3rd Edition of CISPR 16-1-1 [1] in June 2010 FFT-based measuring instruments were introduced for EMI compliance measurements. The publication in the basic standard is a prerequisite that the method can be used by product standards. This is already the case for emission measurement on sound and television broadcast receivers and associated equipment (CISPR 13:2006), lighting equipment (CISPR 15:2013) and for multimedia equipment (CISPR 32:2012). A detailed explanation about the applicability is given in the section How a Basic Standard Comes into Force.

- Partner Content -

A Dash of Maxwell’s: A Maxwell’s Equations Primer – Part Two

Maxwell’s Equations are eloquently simple yet excruciatingly complex. Their first statement by James Clerk Maxwell in 1864 heralded the beginning of the age of radio and, one could argue, the age of modern electronics.

The selection of the measurement time using a FFT-based EMI test receiver needs attention when measuring broadband disturbance and intermittent signals. Furthermore, the use of RF preselection filters is highly recommended for maximum dynamic range and to avoid overload. This is particularly true for quasi-peak measurements of weak pulsed signals in the presence of high amplitude signals. Guidance is given in the section Timing and Dynamic Range Considerations using FFT-based EMI Test Receivers.


Concept of CISPR 16-1-1

Currently CISPR 16-1-1 uses a “black box approach” to define specifications for measuring apparatus. This means that all stated specifications in CISPR 16-1-1 must be met by the measuring apparatus, independent of the selected implementation or technology, in order to be considered sui for measurements in accordance with CISPR standards.

To reflect this approach, a new definition of the term “measuring receiver” has been added in Amendment 1:2010-06 to CISPR 16-1-1:2010-01 [1], it says:

“instrument, such as a tunable voltmeter, an EMI receiver, a spectrum analyzer or a FFT-based measuring instrument, with or without preselection, that meets the relevant parts of this standard”.

- From Our Sponsors -

As a consequence a FFT-based measuring instrument that meets the requirements of CISPR 16-1-1:2010 and its Amendment 1:2010 can be used for EMI compliance measurements. Generally, this comprises the parameters input impedance, detectors, bandwidth, overload factor, VSWR, absolute sine-wave voltage accuracy, response to pulses, overall selectivity, intermodulation effects, receiver noise, and screening.

In addition to the above general requirement the FFT-based measuring instrument shall sample and evaluate the signal continuously during the measurement time. This is essential for capturing impulsive disturbance and intermittent signals. It disqualifies the use of digital storage oscilloscopes for EMI compliance measurements due to the existence of blind times.

How a Basic Standard Comes into Force

Basic standards come into force with dated or undated normative references in product standards:

  • If the reference is undated, the latest edition of the standard shall apply.
  • If the reference is dated, the specific edition of the basic standard shall apply.

CISPR 13:2006 (Ed. 4.2) has undated references to basic standard CISPR 16-1, whereas all other CISPR product standards and IEC generic standards for emission measurements have dated references, see Table 1.

Product Standard

Reference to CISPR 16-1-1

Stability Date

CISPR 11:2010 (Ed. 5.1) — product standard for industrial, scientific and medical equipment (ISM)

CISPR 16-1-1:2006 and its Amendments 1:2006 and 2:2007

2014

CISPR 12:2009 (Ed. 6.1) — product standard for vehicles, boats and internal combustion engines (protection of off-board receivers)

CISPR 16-1-1:2006

2014

CISPR 13:2009 (Ed. 5.0) — product standard for sound and television broadcast receivers and associated equipment

CISPR 16-1-1:2006 and its Amendments 1:2006 and 2:2007

2014

CISPR 14-1:2011 (Ed. 5.2) — product standard for household appliances and electric tools

CISPR 16-1-1:2003

2014

CISPR 15:2009 (Ed. 7.2) — product standard for electrical lighting and similar equipment

CISPR 16-1-1:2003

2013

CISPR 15:2013 (Ed. 8.0) — product standard for electrical lighting and similar equipment

CISPR 16-1-1:2010 and its Amendment 1:2010

2016

CISPR 22:2008 (Ed. 6.0) — product standard for information technology equipment (ITE)

CISPR 16-1-1:2006 and its Amendments 1:2006 and 2:2007

2017

CISPR 25:2008 (Ed. 3.0) — product standard for vehicles, boats and internal combustion engines (protection of on-board receivers)

CISPR 16-1-1:2006 and its Amendments 1:2006 and 2:2007

2014

CISPR 32:2012 (Ed. 1.0) — product standard for multimedia equipment

CISPR 16-1-1:2010 and its Amendment 1:2010

2015

IEC 61000-6-3:2010 (Ed. 2.1) — generic standard for residential, commercial and light-industrial environments

CISPR 16-1-1:2010

2014

IEC 61000-6-4:2010 (Ed. 2.1) — generic standard for industrial environments

CISPR 16-1-1:2010

2014

Table 1: Dated References to CISPR 16-1-1



Therefore, the users of CISPR 13:2006 (Ed. 4.2), CISPR 15:2013 (Ed. 8.0) and CISPR 32:2012 (Ed. 1.0) can immediately employ a FFT-based measuring instrument for EMI compliance measurements if the instrument meets the requirements of CISPR 16-1-1:2010 and its Amendment 1:2010 (Ed. 3.1). For most of the other standards it may be possible to update the references in 2014. CISPR 22 will not be amended any further and will be replaced by CISPR 32 in 2017. For this reason, pure FFT-based measuring instruments will still not be suitable for compliance measurements for quite a long time.

To gain from the dramatically increased measurement efficiency of FFT based receiver technology it is beneficial to use an EMI test receiver, which combines the traditional EMI receiver concept with the FFT-based time-domain scan function in one device. Even if the product standard does not yet allow the FFT based measurement, the method can be used for pre-qualification measurement followed by a measurement according to the traditional analog receiver method at the frequencies identified as critical. (See Figure 1).



1312 F1 fig1

Figure 1: EMI compliance measurements using Time-domain Scan if the product standard does not refer to CISPR 16-1-1:2010 and its Amendment 1:2010

Timing and Dynamic Range Considerations using FFT-based EMI Test Receivers

Two different approaches for implementation of FFT-based receivers are possible:

  • The oscilloscope approach digitizing the RF signal directly using a high dynamic range AD converter
  • The receiver approach using a wide band IF design and digitizing the IF signal.

The limitation with the oscilloscope approach is the AD converter, which needs to have a very high resolution and a high sampling rate to cope with the dynamic range requirements set by CISPR 16 and the bandwidth. Considering some margin for input filtering for a 1 GHz receiver an AD converter with 2.5 GHz sampling rate is needed. To meet the CISPR 16 requirements at minimum 16 bit resolution is necessary. Such AD converters are currently not available. Therefore, auto-range routines and software measures are necessary
to get close to the required performance.

A better approach which guarantees the required performance is to combine both types in one instrument, e.g. direct AD conversion up to 30 MHz input frequency and using e.g. a 30 MHz wide IF with a traditional receiver concept. That way the bandwidth to digitize is limited to 30 MHz putting lower and feasible demands on the AD converter.

This concept offers the following advantages:

  • High dynamic range by limited bandwidth and availability of high resolution and high dynamic 16 bit AD converter.
  • Upper frequency limit of the receiver not limited by the AD converter sampling frequency.
  • The bandwidth filtering and all weighting detectors can operate in real-time, i.e. the complete conducted or radiated emission spectrum can be displayed w/o any interruptions or time gaps.
  • Above 30 MHz the frequency range of interest is subdivided into several segments of e.g. 25 MHz, which are measured sequentially.
  • Long maximum dwell time by low sampling rate, e.g. up to 100 s.
  • Thanks to the limited frequency band used for the FFT an RF pre-selector can be used. It protects the receiver input from overload due to high out of band signals and guarantees correct measurement of weak disturbance signals in presence of strong signals

As a consequence a FFT-based EMI test receiver combines a filter bank with N parallel filters and the stepped frequency scan using a step width according to the FFT width. For this purpose the frequency range of interest is divided into several segments that are measured sequentially, see Figure 2. The scan time Tscan is calculated as:

Tscan = Tm Nseg    (1)

where
Tm is the measurement time for each segment, and
Nseg is the number of segments

1312 F1 fig2

Figure 2: FFT scan in sequence, Source: CISPR 16-2-3 [2]



The measurement time Tm is to be selected longer than the pulse repetition interval of impulsive noise for a correct measurement. If the measurement time is too short pulses are missed, which may result in enormous measurement result errors. In a worst case the measuring receiver may not capture the disturbance signal at all. This is particularly fatal if the segment size has a large width, e.g. 25 MHz or more.

If the pulse repetition interval is unknown, multiple scans with various measurement times using a “maximum hold” function are necessary to determine the spectrum envelope. For low repetition impulsive signals, several (e.g. 10 to 50) scans will be necessary to fill up the spectrum envelope of the broadband component. The correct measurement time can also be determined by increasing it until the difference between maximum hold and clear/write displays is below e.g. 2 dB.

Generally the EMI test receiver must be equipped with preselection filters for providing a sufficient dynamic range for quasi-peak measurements of pulse signals with a low pulse repetition frequency (PRF) and particularly to protect the input circuit of the instrument from overload or damage when measuring weak disturbance signals in the presence of high amplitude signals or strong broadband signals with a bandwidth that is much wider than the instrument’s measurement bandwidth, see Figure 3.
1312 F1 fig3

Figure 3: Principle of preselection



A preselection filter of this type should provide at least 30 dB of attenuation at the frequency of the strong signal. A number of such filters are required to cover the frequency range 9 kHz to 6 GHz.

The dynamic range is limited on the bottom line by the displayed noise level at the requested resolution bandwidth, e.g. 120 kHz in CISPR band 30 MHz to 1000 MHz. The upper limit is the 1 dB compression point of the first mixer. This maximum dynamic range can be used to measure a continuous-wave (CW) signal (narrowband signal) only. If a high level broadband signal is measured, there will be very high levels of distortion products due to nonlinearities of the mixer.

As a consequence, the maximum intermodulation-free input level (maximum indication range) is reduced by the bandwidth factor. See Figure 4.

1312 F1 fig4

Figure 4: Dynamic range and bandwidth factor



Example: The bandwidth factor without preselection is about 26 dB using an IF filter bandwidth BIF = 50 MHz and assuming that the bandwidth of the broadband signal is equal to the RF bandwidth of the EMI test receiver BRF = 1 GHz. The bandwidth factor is about 6 dB using a preselection filter with a bandwidth BPRE = 100 MHz, hence the maximum indication range is 20 dB higher than without preselection.

More Speed with Time-domain Scan and More Insight with Persistence Mode

A new generation of FFT-based EMI test receivers have been developed for CISPR 16 compliant disturbance measurements.  Utilizing a FFT-based time-domain scan, the test receivers can deliver measurement speeds up to 6000 times faster than instruments using the traditional single channel filtering approach.

Frequency scans in the CISPR bands using the peak detector can be performed in just a few milliseconds and even with quasi-peak and average detector it takes just seconds which makes preview measurements with peak detector obsolete. The fast measurement speed is particularly useful if the equipment under test can be operated only during a short period of time, e.g. a starter motor in cars. The time saved can also be used for applying longer measurement times in order to reliably detect narrowband intermittent signals or isolated pulses.

In persistence mode, these FFT-based EMI test receivers write the seamless spectra into a single diagram, see Figure 5.

1312 F1 fig5

Figure 5: Example of a FFT-based EMI test receiver in persistence mode



The color of each pixel indicates how often a specific amplitude occurs at a specific frequency. Frequently occurring signals can be shown in red, for example, and sporadic ones in blue. If signals no longer occur at a specific frequency with a specific amplitude, the corresponding pixel disappears after a user-definable persistence period. This allows users to clearly distinguish between pulsed disturbances, which are present only for very brief periods, and continuous disturbances. In addition, different pulsed disturbances can easily be distinguished from one another.

Example: The shown disturbance spectrum in Figure 5 is caused by an electric motor with poor EMI suppression. A second pulsed disturbance is clearly visible, while it cannot be identified in conventional analyzer mode as it is hidden by the broadband disturbance, see Figure 6.

1312 F1 fig6

Figure 6: Example of a FFT-based EMI test receiver in real-time spectrum mode. The yellow trace represents the current spectrum, the blue trace Max Hold



Conclusions

FFT-based EMI test receivers can be used for EMI compliance measurements in accordance with Amendment 1 to 3rd Edition of CISPR 16-1-1 if this standard is referenced in the product standard or if the reference is undated. Therefore, the users of CISPR 13:2006 (Ed. 4.2), CISPR 15:2013 (Ed. 8.0) and CISPR 32:2012 (Ed. 1.0) can immediately employ a FFT-based measuring instrument for EMI compliance measurements. The users of other standards can use the fast time-domain scan to speed up the time consuming preview measurements.

The use of FFT-based EMI test receivers is motivated by reducing the scan time by several orders of magnitude and to get more insight due to the possibility for applying longer measurement times and enhanced measurement functions like spectrum in persistence mode.

For precise and reproducible measurements the use of preselection filters is highly recommended. favicon

References

  1. Amendment 1:2010-06 to CISPR 16-1-1:2010-01 (Edition 3) Specification for radio disturbance and immunity measuring apparatus and methods – Part 1-1: Radio disturbance and immunity measuring apparatus – Measuring apparatus
  2. Amendment 1:2010-06 to CISPR 16-2-3:2010-04 (Edition 3) Specification for radio disturbance and immunity measuring apparatus and methods – Part 2-3: Methods of measurement of disturbances and immunity – Radiated disturbance measurements



author medler-jens Jens Medler
joined Rohde & Schwarz in 1996. He is responsible for the standardization and application support of EMI test receivers and accessories for both hardware and software and is active member of various CISPR Subcommittees since 1999. This includes CIS/A on EMC measurement instrumentation and methods, CIS/D on equipment on vehicles and internal combustion engine powered devices and CIS/I on information technology equipment, multimedia equipment and receivers. Since April 2007 he is acting as Secretary of CIS/A WG2; the CISPR Working Group on EMC measurement methods, statistical techniques and uncertainty. He is recipient of the IEC 1906 Award.
