New Edition of IEC 62196-1 Published

Electric car reloading/charging on Amsterdam

A new edition has been published by the International Electrotechnical Commission for IEC 62196-1. IEC 62196-1:2014 applies to “Plugs, socket-outlets, vehicle connectors and vehicle inlets – Conductive charging of electric vehicles – Part 1: General requirements.” The update is now available for purchase on the IEC website.

Description*

- Partner Content -

A Dash of Maxwell’s: A Maxwell’s Equations Primer – Part One

Solving Maxwell’s Equations for real-life situations, like predicting the RF emissions from a cell tower, requires more mathematical horsepower than any individual mind can muster. These equations don’t give the scientist or engineer just insight, they are literally the answer to everything RF.

IEC 62196-1:2014 is applicable to plugs, socket-outlets, vehicle connectors, vehicle inlets and cable assemblies for electric vehicles, herein referred to as “accessories”, intended for use in conductive charging systems which incorporate control means, with a rated operating voltage not exceeding:

  • 690 V a.c. 50 Hz to 60 Hz, at a rated current not exceeding 250 A;
  • 1 500 V d.c. at a rated current not exceeding 400 A.

This third edition cancels and replaces the second edition published in 2011 and constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:

a) addition of a preferred operating voltage of 1 000 V d.c.;

b) addition of a preferred rated current of 80 A d.c.;

c) addition of a provision for a combined interface a.c./d.c.;

- From Our Sponsors -

d) description of d.c. configurations (previously under consideration);

e) addition of requirements pertaining to the locking mechanism, the interlock and the latching device;

f) addition of a test for accessories not suitable for making and breaking an electrical circuit under load;

g) addition of requirements and tests for insulated end caps.”

*Description from IEC website.
