New Dual Mode, CW and Pulse TWT Amplifier

Model-367Applied System Engineering, Inc. offers a new Model 367—a Dual Mode, Pulse/CW TWT Amplifier which has been designed to operate TWT’s in the 200-300 watt power range at frequencies up to 18 Ghz.

The RF output pulse is generated by the grid pulse without the use of RF switches. RF output pulse is controlled by the input video pulse. Internal power supplies are DC-DC converter designs with fast loop response times so that output level variations are minimal for any PRF including a non-periodic or burst type PRF. The modular power supplies and grid pulse generator have very low ripple, with attendant low phase noise in the TWT Amplifier.

The modular design of the Model 367 provides convenient accessibility to all elements in the TWT Amplifier.

- Partner Content -

How To Work Safely with High‑Voltage Test & Measurement Equipment

This white paper describes an alternative approach to calibrating high-voltage systems and provides meter and probe safety considerations and general guidance for safely operating high-voltage equipment.

Learn more at the company’s website.
