Versatile Dual Channel 13.6GHz Microwave Signal Generator

saeligSaelig Company Inc. announces the SynthHD Dual-channel RF Signal Generator, an innovative, highly portable device that brings low cost to precision microwave signal generation. The SynthHD is a compact software-tunable, dual channel RF signal generator which can be controlled by a Windows or Linux PC via its USB port, or run as a standalone generator. The SynthHD allows frequency stepping to better than 0.1Hz on each channel, and control of the relative phase between channels to less than a millidegree and amplitude to 0.01dB, producing up to +22dBm of power per channel. The SynthHD’s dual independent channels can be configured to run at two different frequencies, or at the same frequency with different phases in 0.01 degree steps. This allows its use in antenna beam steering applications or quadrature signal generation commonly used in image reject frequency conversion. Based on a 72MHz 32 bit ARM processor, the SynthHD also has nonvolatile on-board memory so it can be programmed to produce any frequency, power, sweep or modulation setting (and combinations) on power-up for running standalone field applications.

Gain is set via the supplied open source Labview GUI, and power levels are settable from -50 dBm to +20 dBm in 0.1dB increments. The SynthHD has powerful software and firmware features such as sweeps, lookup-table frequency and amplitude hopping, pulse modulation, AM, FM, and FMCW pulsed chirps. Its compact size (2.75″ X 2.15″ inches excluding mounting flanges) makes it ideal for field or OEM for equipment use as a basic building block in microwave communications systems.

Applications include: wireless communications systems, antenna beam steering, quadrature oscillator for image reject mixers, RF and microwave building blocks, software-defined radio, radar including FMCW, automated test equipment, radiated immunity pre-compliance testing, electronic warfare and law enforcement, quantum device research, plasma physics, and education.

- Partner Content -

Why Capacitance? Benefits & Applications of Digital Capacitive Solutions

In this paper, readers will discover digital capacitive displacement measurement solutions not possible with conventional analog systems. The following applications address a wide range of industry sectors.

Designed and manufactured in USA by Windfreak Technologies, a designer of low cost, innovative RF products that are in use worldwide in a variety of technical applications, the SynthHD is a highly mobile, low power, lightweight solution for sophisticated RF signal generation needs.
