Ultra-miniature 0.9 mm SuperMini Connectors

southwest microwaveSouthwest Microwave, Inc. has announced the introduction of a series of ultra-miniature 0.9 mm SuperMini DC to 67 GHz connectors.

Connectors in the 0.9 mm SuperMini product line provide the superior performance of Southwest Microwave’s standard-size, high frequency connectors in a miniaturized footprint that is ideal for reduced-size PCB and panel applications. Offering ultra-broad bandwidth and coupling nut mating, this new series includes field-replaceable two and four-hole flange mount and thread-in connectors, solder-on end launch and 4-post vertical launch connectors and direct solder cable connectors. Complete cable assemblies are also available to simplify high-performance interface to 0.9 mm SuperMini connectors.

Along with precision-grade 0.9 mm in-series adapters, the SuperMini line includes several between-series adapters enabling interface to 1.85 mm (V) DC to 67 GHz connectors.

- Partner Content -

Use of a PC-Based Digitizer in Medical Acoustic Microscopy System

Advancing medical acoustic microscopy through innovative digital techniques: maximizing echo detection, enabling high-speed scanning, and achieving precise, synchronized ultrasonic imaging.

Built in the USA to Southwest Microwave’s rigorous performance and quality standards, 0.9 mm SuperMini connectors are rugged and durable, featuring a 360° raised grounding ring and a temperature range of -55°C to 165°C. These connectors provide mode-free operation through 67 GHz, offering well-matched impedance, excellent repeatability, and the industry’s lowest VSWR (1.2:1), insertion loss (0.7 dB) and RF leakage (≤ -100 dB).

For more information, visit www.southwestmicrowave.com.
