Towards a Logic-Based Extension of a Relational Software Tool for Coherent Technical Documentation of Medical Devices

1605_F2_coverThis work presents a novel software tool intended to support compilation of coherent technical documentation. It is based on a relational database system serving as knowledge base incorporating information from the European Medical Device Directive and harmonized standards such as ISO 14971, ISO 980 or ISO 10993-x. In order to achieve increased consistency among sections of documentation for medical devices, a concept for formal description of technical documentation and an additional logic-based system is presented.


Editor’s Note

The paper on which this article is based was originally presented at the 2015 IEEE Product Safety Engineering Society Symposium, where it received recognition as the Best Symposium Paper. It is reprinted here, with permission, from the proceedings of the 2015 IEEE Product Safety Engineering Society International Symposium on Product Compliance Engineering. Copyright 2015 IEEE.

- Partner Content -

How To Work Safely with High‑Voltage Test & Measurement Equipment

This white paper describes an alternative approach to calibrating high-voltage systems and provides meter and probe safety considerations and general guidance for safely operating high-voltage equipment.

With 89% of all revenue in the worldwide medical device industry earned by only 30 companies, 11% of sales revenue accounts for the remaining 27.000 medical device companies around the globe, which vastly categorize as small to medium size enterprises (SME) [1]. Recent studies revealed that particularly these SMEs assess current medical device certification processes as fourth biggest obstacle to innovation [2], although particularly these smaller companies are seen as most innovative [1]. On the contrary complexity of medical devices [3] together with the number of adverse events [4] [5] is continuously increasing.

Manufacturers of medical devices are confronted with various processes and documentation requirements in order to market medical devices in the European Union. Besides quality management requirements such as production and order management, vigilance and market observation, together with thorough customer management, regulatory processes for certification represent mandatory tasks for each manufacturer. An excerpt of these processes is illustrated in Figure 1. In the European Union the certification process of medical devices is regulated by the Medical Device Directive 93/42/EEC (MDD) [6].

Figure 1: Exemplary processes of medical device manufacturers that are subject to rigorous documentation: certification, customer management, quality management
Figure 1: Exemplary processes of medical device manufacturers that are subject to rigorous documentation: certification, customer management, quality management


Content of Technical Documentation

Technical documentation is the fundament to prove conformity with essential requirements stated in Annex I of the MDD. Depending on its potential risk to users and patients, determined by its device class (I, IIa, IIb, III), technical documentation is subject to thorough evaluation by Notified Bodies.

A basic description of the necessary content of technical documentation is given in Annex VII of the MDD. Further examples for the structure and setup of technical documentation are given in [7], [8] and [9].
