TDK Expands Portfolio of EPCOS IEC Inlet Filters

TDK Corporation has announced the expansion of the EPCOS B84771* IEC inlet filter series with two new series.  The B84773* series features an integrated fuse, and the B84776* series has both a switch and a fuse.  All series are also available as versions for medical applications with a maximum leakage current of 2 µA, which makes them particularly suitable for applications in which minimized leakage current is important.

Both new series contain a fuse holder for two fuses with a diameter of 5 mm and a length of 20 mm.  The power switch of the B84776* series is of bipolar design that separates the phase and the neutral conductor.  The rated voltage of the connector filters is 250 V AC at 50/60 Hz.  They are designed for rated currents from 1 A to 10 A.  The B84711* version is even available for rated currents up to 20 A.  The filters are attached to the equipment with screws or snap-in clips.  They are connected via flat connectors with dimensions of 6.3 mm x 0.8 mm or litz wires (B84771*).

- Partner Content -

A Dash of Maxwell’s: A Maxwell’s Equations Primer – Part One

Solving Maxwell’s Equations for real-life situations, like predicting the RF emissions from a cell tower, requires more mathematical horsepower than any individual mind can muster. These equations don’t give the scientist or engineer just insight, they are literally the answer to everything RF.

All filters were designed for maximum ambient temperatures of 85o C and are RoHS-compatible.  The B84771* versions already have UL/CSA/ENC approval.  Both the B84773* and B84776* series have received UL/CSA approval.  ENEC approval is pending.

Typical applications of these new IEC inlet filters are switch-mode power supplies, office and measuring instruments, arcade machines, electronic POS systems, small electrical machines, fitness equipment, and equipment for medical applications.

For additional information, visit www.epcos.com.
