Schurter’s Shock-Safe Fuseholder Series is UL Rated 16A @ 400 VAC

Schurter has announced the FPG fuseholder series with increased ratings up to 16A @ 400 VAC. The increased voltage rating expands application possibilities for this popular fuseholder series, which offers seven different mounting options: front or rear panel mount, threaded neck panel mount, snap in or press in panel mount, through hole or SMD PCB mount. In addition, the FPG series is now available in a special thermoplastic version that meets the latest requirements of IEC 60335-1 edition 4.0 for appliances in unattended use including the enhanced requirements of glow wire tests according to IEC 60695-2-12 and -13.

The FPG series is available with IP40 or IP67 seal protection for 5x20mm fuses with front and rear panel mounting and either vertical or horizontal PCB mounting. Terminal connections are made with quick-connect, solder and PCB pins. The compact FPG series comes complete with fuse carriers and slotted or finger grip caps.

The new UL approval for the increased voltage rating is according to UL4248-1/UL 512 and CSA C22.2 for 16 A at 400 VAC. VDE approval is according to IEC 60127-6 for 10 A at 250 VAC. The FPG fuseholder series has a rated power acceptance of 2.5 W @ 10 A with an operating temperature of -40°C to 85°C. The series meets shock-safe requirements according to IEC 529.

- Partner Content -

Shielding Effectiveness Test Guide

Just as interference testing requires RF enclosures, isolation systems in turn need their own testing. This document reviews some of the issues and considerations in testing RF enclosures.

Additional information on the FPG series can be found on Schurter’s website at http://www.schurterinc.com/fuses.
