Rugged, Low-Resistance Silver Connector

silver zebra The Fujipoly Series 5002 Silver Zebra® connector is an excellent low-cost, long-life option for LCD to printed circuit board connections.  It is also a great choice as a board to board connector where space is limited.  This Zebra® connector delivers a current carrying capacity up to 300 mA per square .040”and exhibits a contact resistance of less than 500 mΩ.

The versatile interconnect device creates redundant electrical contact through a unique product design that incorporates 240 alternating layers of silver-filled conductive elastomer and non-conductive silicone material per inch of connector.  This precise construction provides a centerline pitch between layers of .004” (.10mm) and allows for .015” (.381mm) pad spacing on the PCB.
