RF & Microwave Filters Available from Stock

TTE filters

TTE Filters, a US-based manufacturer of high-reliability RF filters and microwave filters for demanding communication and signal processing applications, announced the introduction of a stocked Lowpass Chebyshev passive filter series – LC9S – providing off-the-shelf convenience and immediate delivery. The series was featured at the 84th Microwave Measurement Conference in Boulder, Colorado earlier this month.

The 9-pole filters in the LC9S Series deliver fast roll-off, an insertion loss of 1.0dB maximum and 50 Ohm terminations. Nine part numbers are available, each at a specific -1dBc passband frequency, from 30 MHz to 3 GHz. The series offers stopband attenuation of -40dBc at 1.5:1 ratio (rejection frequency from 45 MHz to 4.5 GHz) and -60dBc at 2:1 ratio (rejection frequency from 60 MHz to 6 GHz). Depending on frequency, the filters have input power of 5 or 10 watts max and utilize one of two SMA female connectorized cases. Operating temperature is 0°C to +70°C. RoHS-compliant parts are available.

- Partner Content -

Shielding Effectiveness Test Guide

Just as interference testing requires RF enclosures, isolation systems in turn need their own testing. This document reviews some of the issues and considerations in testing RF enclosures.

LC9S filters are designed for use in cellular, data acquisition, electronic support, radar, satellite, sonar, telecommunication, telemetry and wireless applications in commercial, industrial, medical and military/defense environments.

Complete technical information is available at the company’s website.
