Pasternack Introduces New Series of Low PIM Cable Jumpers

Pasternack Enterprises, Inc. has introduced an all new series of low PIM cable jumpers with formable coax. These new assemblies are designed for low passive intermodulation (PIM) applications including use in black boxes, test equipment racks and cabinets, distributed antenna systems (DAS), and lab testing.

Pasternack’s low PIM formable cables are made using a tin-filled braid that produces a hand formable, solid outer conductor wall, making them perfect for installation into tight places. These RF cables are available with two different coax diameters sizes including 0.163” and 0.276” and connector options include 7/16 DIN, 4.1/9.5 mini-DIN, Type N, and SMA. The robust connectors’ TriMetal plating, soldered connection point and precise coaxial cable construction produce reliable low PIM performance for the life of the assembly.

The formable cable jumpers boast outstanding PIM performance of -160 dBc and 1.25:1 VSWR. Between-series configurations can be ordered with SMA, Type N, and 7/16 DIN connector combinations, while in-series cables using 4.1/9.5 Mini DIN connectors are also available. Pasternack’s low PIM jumpers operate from DC up to 6 GHz depending on the desired configuration. These RF cable assemblies are available for same-day shipment in two popular lengths including 100 and 200 centimeters (cm). Custom lengths are available upon request with slightly longer lead times depending on the customer’s specific needs. Each assembly is 100% RF and PIM tested prior to shipment.

- Partner Content -

A Dash of Maxwell’s: A Maxwell’s Equations Primer – Part One

Solving Maxwell’s Equations for real-life situations, like predicting the RF emissions from a cell tower, requires more mathematical horsepower than any individual mind can muster. These equations don’t give the scientist or engineer just insight, they are literally the answer to everything RF.

For more information, visit at http://www.pasternack.com/pages/Featured_Products/low-pim-cable-jumpers-with-formable-coax.htm
