ON Semiconductor Introduces High Performance Clock Distribution Solutions for Networking and Communications Applications

ON Semiconductor has announced the release of two new clock distribution ICs.  Operating from a supply voltage of 2.5V and 3.3V, the high performance NB6L56 2:1 clock/data multiplexer’s differential inputs incorporate internal 50 Ohm (Ω) termination resistors accessed through the VT pin. This feature allows the device to accept a broad variety of logic level standards, including low voltage positive emitter coupled logic (LVPECL), current mode logic (CML) and low voltage differential signaling (LVDS). Outputs are 800 millivolts (mV) emitter coupled logic (ECL) signals. The additive clock and data jitter produced is minimal even when operating at 2.5 Gigahertz (GHz) and 2.5 Gigabits/second (Gbps) rates respectively. This makes the NB6L56 highly optimized for use in SONET, Gigabit Ethernet and Fiber Channel network infrastructure, as well as other telecom and data communication applications.

The NB3F8L3010C is a 3:1 multiplexer and a 1:10 clock/data fanout buffer targeted at networking and communications applications. Operating from a 3.3 V or 2.5 V core supply, the device has differential inputs which accept LVPECL, LVDS, host clock signal level (HCSL) and stub series terminated logic (SSTL) signals. It has a total of 10 single-ended LVCMOS outputs each capable of running at 200 megahertz (MHz). Output skew is typically kept to just 10 picoseconds (ps). Both the NB3F8L3010C and NB6L56 devices support an industrial temperature range of -40 °C to 85 °C.

For more information, visit http://www.onsemi.com.
