New Way to Transfer Thin Semiconductor Films Developed

New Way to Transfer Thin Semiconductor Films Developed | In Compliance Magazine

A new technique to transfer thin semiconductor films onto arbitrary substrates has been developed at North Carolina State University. This method is quicker than existing techniques and allows the films to be transferred from one substrate to another without creating any cracks.

The researchers use the physical properties of molybdenum sulfide (MoS2), a commonly used material in the semiconductor industry, to transfer the thin film using room temperature water, a tissue, and a pair of tweezers. This new method could lead the way for advances in flexible computing or photonic devices.

- Partner Content -

A Dash of Maxwell’s: A Maxwell’s Equations Primer

Through mathematical precision, Glen Dash offers a comprehensive exploration of Maxwell's Equations, revealing the intricate mechanisms by which electric and magnetic fields interact to explain electromagnetic radiation and fundamentally shape our technological understanding of modern electronics and communications.

Watch a video to see how fast this new method is for transferring semiconducting thin films from one substrate to another.
