METZ CONNECT Introduces Keystone Compatible EDAT Modul CAT 6A K Jack

METZ CONNECT introduces a new keystone compatible EDAT Modul CAT 6A K jack. Intended for use with screened or fully shielded Ethernet cable, the K jack is fully shielded (zinc die cast) and uses IDC technology to facilitate an easy to use field termination. No special tools are required to terminate the two-piece design which features color coded terminals for easy loading according to either TIA568 A or B wiring schemes. In compliance with ISO/IEC 11801, the K jack is a fully certified CAT 6A component, and is perfect for use in high speed applications including storage area networks, data centers, multimedia, security and more.
Product Specifications:

  • Modular termination unit Cat.6A, RJ45
  • Component testing for Cat.6A to ISO/IEC 11801 Ed.2.2:2011-06, DIN EN 50173-1:2011-09, TIA/EIA-568-C.2 (2009-08) and IEC 60603-7-51Ed.1 (12/2008), certified to GHMT
  • Compliance with class EA to ISO/IEC 11801
  • Ed.2.2:2011-06, DIN EN 50173-1:2011-09
  • Tested: Link up to 500 MHz
  • For 10 GBit Ethernet (IEEE 802.3an)
  • Suitable for Power over Ethernet (PoE, PoE plus and UPoE)
  • Easy to install connection of 2 to 4 pair data lines
  • AWG 26/1 – 22/1 and stranded wires with 7 copper conductors AWG 26/7 to BTR 8-fold insulation displacement connectors (IDC)
  • Marking of conductor assignment to T568A and T568B
  • Easy and fast insertion of wire pairs in E-DAT modul stuffer cap
  • Module housing made of refined zinc die-casting
  • Mounting without special tools
  • Strain relief with cable tie at the module
  • Mounting version: Keystone
  • Cable feed 180°
