Keysight Technologies, Inc. introduced continuous simultaneous acquisition and readout (CSR) for its U5303A 12-bit PCIe digitizer. In addition, complete data recording software applications are available, such as digitizer streaming (application option CB0) and digital down-converter streaming (application option CB1).
The U5303A firmware option CSR allows engineers to perform acquisition and readout simultaneously and in a continuous way. They can use several mechanisms to adapt the acquisition data rate to the targeted application. A gapless acquisition can be sustained at a high data rate due to the PCIe Gen2 x 8 interface. An entire range of new application possibilities are enabled by the CSR option, which includes real time GPU-based data processing systems and data recording systems.
CB0 is an application option which implements a real time digitizer data recorder. Based on the CSR architecture, the CB0 provides a command line interface and an easy to use data viewer. Recording performance up to 1 GB/s are ensured in a specific qualified system.
CB1 provides the same functionality as CB0 and adds real time digital down-converter functionality. Recording performance up to180 MHz instantaneous bandwidth are ensured in a specific qualified system.
“Numerous test scenarios require gap-free or continuous acquisition of digitized data for minutes, hours or days.” said Keysight’s Giovanni Lucia, R&D engineer for hardware and firmware. “Signal monitoring, software defined radio, atmospheric research, telemetry systems and medical imaging are examples of such applications. We designed the CSR option with the intent of providing an easy and effective implementation to simplify the integration in any OEM system. Furthermore, the CB0 and CB1 applications provide a reliable and cost effective data recording system for customers who want a ready to use solution.”
The continuous simultaneous acquisition and readout CSR firmware option, as well as the digitizer streaming CB0 and digital down converter streaming CB1 application options are available now for the 12-bit U5303A PCIe high-speed digitizer.
Keysight high-speed digitizers are the result of more than 300 years of cumulative research and development experience in analog-to-digital conversion technology. This deep understanding allows Keysight to achieve the most effective and reliable analog-to-digital conversion with the highest resolution and fastest sampling rates. Information about the technology and its applications is available at www.keysight.com/find/high-speed-digitizers.
