Integrated Light Pipe in AC Outlets Offer Intelligent Power Capabilities in PDUs

SHURTERSCHURTER announced the capability of integrating a fiberglass light pipe as an optional feature to its popular appliance outlets. The light pipe provides operational or other function status indication in power distribution units (PDUs). It is designed to channel light from LEDs on the pc board to the front of the connector. The new technology offers flexible design options including the number of light pipes, 1-4, as well as options for light pipe lengths and diameters. The flexibility of design allows for efficient customer-specific solutions while enabling increased opportunity to signal status information from the power grid to the user.

The light pipes installed in the outlet are designed to channel light coming from LEDs mounted on a printed circuit board to the surface of the outlet. Each outlet generally has its own circuitry and, depending on the complexity of the monitoring system, may offer several types of indicating functions. The outlets are capable of providing up to four light pipes, one in each of the four corners of the connector. The side of the outlet with the ground pin provides extra space around the two corners, allowing for the most prominent and thus popular position.

A typical application consists of power distribution units used in data centers. Today, these units are most likely to have monitoring systems with indicating display panels or controls. These display panels are often centrally located. With SCHURTER’s new appliance outlet, it becomes easier to extend the systems monitoring capabilities from the centralized display to each outlet. Service technicians are able to clearly see which systems are working properly, or respond to required maintenance adjustments. A connector could, for example, signal an outage with a red LED, or a critical power consumption pattern with a yellow LED. In this way, both repairs and preventive maintenance can be done more simply and efficiently.

- Partner Content -

A Dash of Maxwell’s: A Maxwell’s Equations Primer – Part One

Solving Maxwell’s Equations for real-life situations, like predicting the RF emissions from a cell tower, requires more mathematical horsepower than any individual mind can muster. These equations don’t give the scientist or engineer just insight, they are literally the answer to everything RF.

SCHURTER’s IEC 60320-1, style F, rated UL/CSA 15 A @ 250 VAC and IEC rated 10 A @ 250 VAC and, style J, rated UL/CSA 20A @ 250 VAC and IEC 16A @ 250 VAC with light pipe provide simple, user-friendly solutions utilizing intelligent power capabilities within power distribution today.
