How to Fulfill AS 9100 Traceability Requirements as a Defense Subcontractor

Quality and Accountability in the Aerospace Sector

The aerospace industry continues to heat up, along with the need for systematic traceability that maintains quality while reducing costs. Considering that unmanned aerial vehicles (UAVs) like the RQ-4 Global Hawk can cost upwards of $130 million and other military aircraft like the B-52 can cost approximately $53 million, malfunctions of any kind can be disastrous. Even commercial aircraft like the Boeing 737 can cost between $51.5 million and $87 million, depending on the model. Malfunctions are not only costly, but can be life threatening.



: Unmanned military aircraft like this MQ-9 Reaper require precise traceability throughout the supply chain. Source: United States Air Force
Unmanned military aircraft like this MQ-9 Reaper require precise traceability throughout the supply chain. Source: United States Air Force



- Partner Content -

VSWR and its Effects on Power Amplifiers

Voltage Standing Wave Ratio results from an impedance mismatch between a source (an amplifier) and a load (test application). This mismatch can influence the performance of the source.

The construction and maintenance of aircraft involves a variety of products, including wide-bandwidth amplifiers, high-voltage connectors, electromagnetic interference (EMI) filters, DC-DC converters, laser rangefinder receivers, onboard computers, lighting, communication systems and serial bus interfaces. These products, along with parts and supporting equipment/subsystems are designed and manufactured by dozens of companies with different specialties. One thing all of these suppliers must have in common is a concern for quality and compliance.

For these reasons, manufacturers supplying the aerospace industry face the decision whether to become AS 9100 certified. An international quality management system standard, AS 9100 builds on ISO 9001 and adds requirements specific to the aircraft, space and defense industry. For those new to this standard, it combines and harmonizes AS 9000, ISO 9001 and Europe’s prEN 9000-1 quality systems. It also defines specialized areas within an aerospace quality management system such as acquisition traceability, configuration management, product documentation and control of work performed outside the supplier’s facilities.



A highly trained assembler works on a traveling wave tube amplifier (TWTA), of which every component meets stringent traceability requirements. Source: dB Control
A highly trained assembler works on a traveling wave tube amplifier (TWTA), of which every component meets stringent traceability requirements. Source: dB Control



To satisfy quality requirements of the U.S. Department of Defense (DoD), the National Aeronautics and Space Administration (NASA) and the U.S. Federal Aviation Administration (FAA), suppliers must be able to trace all components of a failing part back to its origin. To do this, and ultimately hold suppliers accountable for providing reliable products, they must have the ancestry of those components on file.

- From Our Sponsors -

At its core, AS 9100 consists of a “Plan-Do-Check-Act” cycle that focuses the organization on its key processes, planning, reviewing and continual improvement. From its inception, one of the tenets of AS 9100 has been to mandate what a quality management system must achieve, but not how to achieve it – leaving the latter up to the supplier. As a result, the way the requirements of the standard are met can vary dramatically from supplier to supplier.

Some manufacturers that are ISO 9001 certified create their own systems that meet AS 9100 requirements. The AS 9100 standard’s flexibility allows these companies to fine-tune existing quality management systems and avoid investing the considerable time and money required to purchase and implement new enterprise-level software. For example, dB Control (an international defense electronics manufacturer for which I’m the Operations Manager), was able to modify its existing quality system to meet AS 9100 requirements. Even though its system was not originally designed for part tracking and traceability from procurement through final build and shipping, the company scrupulously monitors the process. Additionally, its quality manual and documentation remain extremely comprehensive and thorough.



Regardless of AS 9100 certification, manufacturers must aim for continual improvement of the quality management system. Source: dB Control
Regardless of AS 9100 certification, manufacturers must aim for continual improvement of the quality management system. Source: dB Control

To illustrate, when a part arrives, it is received into the system, which then issues a receiving transaction number that begins the process of recording all subsequent information and becomes the internal lot number for that part. When the part gets kitted and sent to production, that tracking number is recorded on the stock issue report. This tracking continues as the component becomes part of larger and larger assemblies.

The end result? A build package that includes all routing documents created throughout the process. This package now contains a very detailed “as-built” list. Even though this process is only minimally automated, the company knows which parts from which lots were used to build which products and sold to which customers, all while maintaining full traceability for each part back to its origin. Should the need arise, it also makes it possible to produce any associated certificates, test reports and other supporting documentation quickly.



One step of the quality assurance process: an experienced technician tests a high-voltage TWT amplifier. Source: dB Control
One step of the quality assurance process: an experienced technician tests a high-voltage TWT amplifier. Source: dB Control

Going Above and Beyond the Standard

For manufacturers supplying hardware that will be used in space, the requirements for “hi-rel” and space-qualification vastly exceed those of AS 9100. Considering that repairs are generally impossible for equipment orbiting the Earth, component failure is not an option. For these companies, meeting the AS 9100 standard is considerably less difficult – more like dotting i’s and crossing t’s. Companies must maintain extraordinary levels of traceability, including the serial and lot numbers for every component in an assembly. Traceability must also be maintained from the materials level through plating and a broad array of other functions that are well beyond what is required in AS 9100 as it applies to the aerospace community as a whole.

For example, a manufacturer required to meet the MIL-PRF-38534 QML for hybrid microcircuits must meet specifications that demand extraordinary traceability, require extensive accountability for manufacturing control, worst-case analysis, shock, vibration, thermal cycling, and many other factors. Serial numbers, part numbers and date codes must be present on every product. Traceability must be provided all the way back to original materials and components, i.e., the wafer number in the case of a semiconductor or the lot number for a packaged part. This requires strict controls on materials procurement, kitting, and record retention during manufacturing – an expensive, labor-intensive process.

The benefit to the customer is that, if a problem develops even five years after the product was delivered, the manufacturer can trace the individual

failed component, in which products it was used, as well as the customers who received them. Many terrestrial platforms also require this high level of detail and testing, especially in military and mission-critical applications, but this is usually flowed down contractually regardless of what certifications a subcontractor may hold.

AS 9100D Compliance Beckons

The latest revision of the standard (AS 9100D) is expected to be released sometime before the end of 2016. Although the new standard will contain many edits and clarifications to its predecessor, its most significant and broad-based enhancements will be to planning and risk management. In fact, language specifically dedicated to risk management is present throughout.

In general, AS 9100D is expected to increase requirements for demonstrating compliance in more detail, from internal auditing to corrective action, while also mandating the ability to provide objective evidence of compliance, whether a document, chart, or diagram, thus eliminating some gaps in the previous version. It is generally acknowledged among QA managers that the forthcoming changes within AS 9100D were driven by the aerospace industry rather than the aircraft industry. Thus validation of tests, risk analysis, assessment and mitigation, processes that were touched upon in the current version, are now essential.

In addition to taking a major step forward in risk mitigation, AS 9100D will expand sections of its predecessor to better define compliance requirements. In short, it calls for more detailed documentation and thus potentially greater traceability.

As the AS 9100D standard will require significantly higher levels of effort to remain compliant, enterprise software and the automated accountability it provides can be a significant benefit. For example, rather than simple tooling documentation, a procedure must be in place and records kept as to when a tool will be serviced or replaced and whether it in fact was replaced. Enterprise software can automate this and many other functions. In larger companies, this has become a necessity. Another benefit of enterprise software is that it can make companies more productive without adding massive amounts of overhead and touch labor which can actually complicate, rather than streamline, the process.

Customers Influence Certification Decision

The DoD, the FAA and NASA endorse AS 9100 certification but do not typically demand it. Since suppliers serving the defense and aerospace markets are not required to be certified, in practical terms the decision is often determined by whether or not a major customer requires it. For example, if a manufacturer’s customers are prime contractors such as Boeing, Rolls Royce, United Technologies or Raytheon, certification can become a necessity. In addition, if a manufacturer is supplying a component to a contractor further up the supply chain and the ultimate recipient of the end product requires certification to AS 9100, the manufacturer may find itself in a situation that much resembles a full-blown certification audit. With this comes the need to prove compliance and adherence to key aspects of the standard.

For many manufacturers, the customer with the most strenuous requirements dictates whether ISO 9000 alone or AS 9100 (which incorporates, adds to and amplifies the requirements of ISO 9001) is necessary. At the very least, AS 9100 is beneficial because it forces manufacturers to pay strict attention to quality. At its best, the standard provides a very high level of accountability, especially in the case of first article inspection – the standard’s furthest reach into the domain of military specifications.

Not only does AS 9100 provide a single standard for all suppliers, it enables greater focus on key customer requirements, improved product and process quality, reduced quality variation, increased efficiency, potential reduction of second-party audits and precise traceability throughout the supply chain. Subcontractors who provide products to AS 9100-certified prime contractors must maintain the same standards for quality as their customer. However, as specific procedures for traceability remain at the discretion of the company, a manufacturer that is ISO 9001 certified can fulfill AS 9100 traceability requirements by using accounting data to track part lots.

By tapping into an existing methodical system, data accuracy is ascertained. Plus, using accounting data to fulfill traceability requirements comes at no additional cost, as the accounting system is already in use. A company can create a build package that includes every routing document created throughout the process. This make it possible to find what lot tracking number was given to every part, trace it back to its supplier and produce any associated certificates/test reports at a moment’s notice.

AS 9100 At-a-Glance

Since AS 9100 certification is not a mandatory requirement of many prime contractors, every manufacturer should evaluate whether or not ISO 9001 certification alone will suffice.

While enterprise software is an investment, it can ultimately reduce costs as a company grows.

Subcontractors facing compliance challenges stand to benefit a great deal from forming a solid and communicative relationship with their customer’s quality representatives. In the spirit of mutual success, the customer is more than likely to impart a treasure trove of practical solutions developed from years of experience.



Vlad DiNatale is the Operations Manager at dB Control (Fremont, CA), a subsidiary in the Electronics Technologies Group (ETG) of HEICO. For more information, call 510-656-2325.
