Highly Robust MEMS-Based Pressure Sensors for Direct & Oil-Filled Sensing Systems

melexis pressure sensorMelexis has introduced two new pressure sensor products which combine high sensitivity and strong linearity. Fully automotive qualified (exceeding AEC-Q100 requirements), the MLX90815 and MLX90816 are discrete micro-electro-mechanical (MEMS) devices for measuring absolute pressure in demanding operational environments. The MLX90815 is designed for optimal performance when determining pressures from 0 to 30 bar absolute, while the MLX90816 covers full scale pressures ranging from 30 bar to 50 bar absolute. Both have a maximum deviation in their linearity of just 0.2% FS. Typical sensitivity for the MLX90815 is 1.5mV/V/bar and for the MLX90816 it is 0.5mV/V/bar.

The sensor element incorporated into every one of these MEMS devices consists of a piezo-resistive Wheatstone bridge connected to a micro-machined silicon pressure membrane, fabricated using Melexis’ own proprietary process technology. As pressure is applied to the membrane, a differential voltage change occurs across the outputs of the Wheatstone bridge while a bias voltage is applied to the bridge inputs.

The MLX90815 and MLX90816 pressure sensors can be supported by the company’s high performance sensor interface chips (such as the MLX90320) in order to carry out conditioning of the output signal. These sensors are highly suited to a variety of automotive pressure monitoring applications, as well as industrial process controls, domestic appliances, medical equipment and consumer electronics gadgetry.

- Partner Content -

A Dash of Maxwell’s: A Maxwell’s Equations Primer – Part One

Solving Maxwell’s Equations for real-life situations, like predicting the RF emissions from a cell tower, requires more mathematical horsepower than any individual mind can muster. These equations don’t give the scientist or engineer just insight, they are literally the answer to everything RF.

Each exhibiting an operational temperature range of between -40°C and 150°C, the MLX90815 and MLX90816 are able to maintain stable operation in harshest of working conditions. These devices can be employed directly in conventional non-corrosive/non-aggressive media or incorporated into oil-filled sensor modules to further heighten robustness.

For more information visit www.melexis.com.
