High Gain Amplifiers for Commercial and Military Radar Released by Pasternack

Pasternack Enterprises, Inc. released a new portfolio of L and S band high gain amplifiers covering 1.2 – 1.4 GHz and 3.1 – 3.5 GHz specifically used for commercial and military radar applications as well as observation satellites and communications systems.

Pasternack’s new high gain amplifier modules are optimized for 1.2 – 1.4 GHz and 3.1 – 3.5 GHz radar applications, packaged in hermetically-sealed metal enclosures and exhibit outstanding performance in high gain, gain flatness, high output power and low noise. These RF amplifiers utilize a hybrid microwave integrated circuit design and advanced GaAs pHEMT technology to produce an unconditionally stable module. They are also designed with built-in voltage regulation, bias sequencing, and reverse bias protection for added reliability and over-voltage protection is installed externally for easy repair.

A total of six new L and S band high gain amplifiers are offered in this latest release from Pasternack. Two of those products are low noise amplifiers (LNA) which demonstrate noise figure performance of 1.1 dB to 1.5 dB at high gain levels of 40 dB typical gain while also exhibiting excellent gain flatness. Also offered are 10 Watt and 20 Watt high power amplifiers that have exceptional gain performance of 40 – 47 dB with 1.0 dB to 1.5 dB gain flatness. Pasternack is also releasing an L of 1.5 dB.

- Partner Content -

Magnetic Field Conversions

This download provides a table of magnetic field conversion factors of microvolts-per meter, gauss, picotesla, microampere-per-meter, weber per-square meter, and gamma with values of either 0 db or 1 as a starting point.

The new 1.2 – 1.4 GHz and 3.1 -3.5 GHz high gain amplifiers from Pasternack are in -band driver amplifier that displays solid gain performance of 47 dB while delivering competitive gain flatness stock and available to ship the same-day. For additional details, visit http://www.pasternack.com/pages/Featured_Products/l-and-s-band-high-gain-amplifiers.htm
