FieldFox Analyzers Provide Handheld Cable Test Solution

Keysight-FieldFoxKeysight Technologies, Inc. introduced two cable test options for its FieldFox handheld analyzers, a comprehensive handheld solution for cable testing.

Cables (e.g., waveguide, coaxial and twisted-pair) are the most widely used components in RF and microwave communication systems. They are also the leading cause of their failure. During maintenance of these systems, engineers and technicians need to measure cable performance (e.g., return loss and voltage standing wave ratio (VSWR)), while also identifying fault locations and their cause (e.g., bad insulation, kinks and water ingress). Such testing requires a cable and antenna analyzer, network analyzer, signal generator and power meter; all of which must be transported and set up for testing in the field. The process is error prone and leaves the instruments subject to accidental damage.

The new Time Domain Reflectometry (TDR) cable measurement option enables TDR measurements for the cable and antenna analyzer. With this option, Keysight’s FieldFox analyzers become the ideal tool for any cable system test. The option complements the analyzers’ return loss (RL) and distance-to-fault (DTF) measurements. Furthermore, it measures impedance changes along the cable and helps identify specific faults, while the analyzer’s RL measurement capability exposes mismatch of cable connections and DTF capability indicates faults and poor connections along the cable.

Measuring long microwave cables in the field proves to be a very challenging task and requires instruments to provide a high dynamic range and fast and reliable results. The new FieldFox Extended Range Transmission Analysis option addresses one of the major challenges to measuring cables in the field; measuring in-situ, long lossy microwave cables. Accessing both ends of the cables or waveguides at the same time is difficult. Using a signal generator with a broadband detector or power sensor to measure cable loss can be a slow process, it also is prone to external interference and does not allow high levels of dynamic range. Deploying a benchtop solution in the field to make the measurement is also non-ideal due to its large size and cost.

With Extended Range Transmission Analysis, two FieldFox instruments are deployed at each end of the measured cable. One analyzer acts as a source, while the other acts as a receiver. Both instruments are step synchronized with hardware triggers. By taking advantage of Keysight’s proprietary InstAlign spectrum analysis technique, engineers and technicians can use this configuration to make very accurate cable loss measurements without calibration and warm up. This option can also be configured with frequency-offset to measure devices such as mixers and converters.

More information about is available at www.keysight.com/find/FieldFox.
