Excelsys UltiMod Modular Off-Line Power Supplies Have 5-Year Warranty

Excelsys Technologies has announced the introduction of the new UltiMod range, the first in its class to carry a 5-year warranty. The UltiMod series of power supplies provides up to 12 outputs and 1200W in a compact 1U format. Typical applications for the Excelsys UltiMod series include clinical diagnostic equipment, medical lasers, dialysis equipment, radiological imaging, clinical chemistry, industrial automation and machines, test and measurement, automation equipment, printing, telecommunications, audio and broadcast equipment.

The UltiMod Series provides up to 12 fully isolated DC outputs ranging from 1.5V to 58V provided from a range of single and dual output modules (powerMods). The feature-rich powerMods provide a suite of output signals and user configurable functions increasing design-in flexibility. User configurable functions include local and remote output adjustment, adjustable current limit, alternative current limiting techniques and inhibit/enable functions.

The Excelsys UltiMod is simple to configure for any application. Two versions of the AC input front ends (powerPacs) are available to accommodate either 4 (UX4) or 6 (UX6) output modules. The powerPacs carry dual certification: 2xMOPP, EN60601-1 3rd Edition for medical applications and EN60950 for industrial applications. Ultimod units are also SEMI F47 compliant. The UX4 delivers up to 600W, the UX6 up to 1200W.  All UltiMod products can with stand shock >60G, per MIL STD 810G and will start-up at -40ºC.

- Partner Content -

A Dash of Maxwell’s: A Maxwell’s Equations Primer – Part One

Solving Maxwell’s Equations for real-life situations, like predicting the RF emissions from a cell tower, requires more mathematical horsepower than any individual mind can muster. These equations don’t give the scientist or engineer just insight, they are literally the answer to everything RF.

A comprehensive Designer’s Manual is available for download at http://www.excelsys.com/ultimod-landing-page
