Estimating Reverberant Electromagnetic Fields in Populated Enclosures by Using the Diffusion Model

Editor’s Note: The paper on which this article is based was originally presented at the 2018 IEEE International Symposium on Electromagnetic Compatibility & Signal/Power Integrity (EMC, SI & PI), where it received recognition as the Best Symposium Paper. It is reprinted here with the gracious permission of the IEEE. Copyright 2018 IEEE.


Introduction

In order to predict the shielding effectiveness of an enclosure, it is necessary to determine the electromagnetic field inside it. In real cases, an enclosure always has contents. Previous work has shown that the contents of an enclosure affect the shielding effectiveness because they absorb some energy and decrease the internal field [1]. The power balance (PWB) method has been widely used to study shielding problems of electrically large enclosures [2]. It stems from electromagnetic topology, dividing one big complex problem into several smaller and simpler ones [3]. For example, to a perforated and loaded enclosure, the internal energy loss consists of three parts: wall absorption, content absorption and aperture leakage. In this way, the walls and contents are characterized by their absorption cross sections (ACS) and the apertures are characterized by their transmission cross sections (TCS). The shielding effectiveness of the enclosure can then be calculated from the ACS and TCS [4]. The key feature of the PWB method is that it only considers average energy, so the detailed geometry of the contents is not required. Therefore, it takes much less computer resources than full-wave solvers.

One of the basic assumptions of the PWB method is that in the steady state, the electromagnetic energy in an enclosure is completely diffuse and therefore uniformly distributed throughout the volume. This is true for low loss circumstances in which multiple reflections from enclosure walls lead to uniform and isotropic field. However, for moderate or high loss cases, the distribution of energy is no longer uniform and the PWB method does not account for this [5].
