Delcross Announces Electromagnetic Interference Toolkit (EMIT) Release 4.0

softwareDelcross Technologies announces the release of the EMIT (Electromagnetic Interference Toolkit) Version 4 software. EMIT V4.0 combines an analysis engine that is over 100x faster than the previous release, with intuitive new RF system configuration setup and EMI margin result views. EMIT V4.0 gives RF system engineers a complete and intuitive picture of the sources of RF cosite EMI margin violations and contributing signal paths for scenarios involving many integrated or co-located RF systems.

EMIT is a software framework for cosite simulation and management of installed RF systems. These RF systems may consist of multiple receivers, transmitters, antennas, interconnected components and installation platforms. EMIT manages installed RF system performance data, simulates intra-system RF EMI effects, and helps to mitigate EMI issues, resulting in a comprehensive database/model maintainable over the life of a host platform.

EMIT V4.0 features new intuitive interfaces for RF system configuration, RF cosite interference analysis, and for viewing EMI margin results. A new Configuration Diagram lets you configure RF systems graphically with intuitive “drag and drop” component placement and connection in a schematic display format. RF systems can now be configured with multiple radios, and have connections to separate Tx and Rx paths, and to connect multiple antennas, radios and components. New RF components like circulators, isolators, multiplexers and power dividers have been added to enable, for example, multi-band antennas to be shared between RF systems. For the benefit of military customers, RF systems can also be defined in a convenient new DD-1494 form entry mode.
