Chroma Adds New 10MHz HF LCR Meter

Chroma Adds New 10MHz HF LCR Meter | In Compliance Magazine

Chroma Systems Solutions announced the addition of the Chroma 11050 HF LCR Meter precision test instrument designed to accurately measure and evaluate passive components at high speeds. Its measurement capabilities cover the primary and secondary parameters required for testing the inductance, capacitance, resistance, quality factor and loss factor of passive components. The HF LCR Meter has a broad testing frequency range from 1kHz to 10MHz suitable for analyzing the components’ characteristics under different frequencies and test levels from 10mV to 5V. Its 0.1% basic measurement accuracy provides stable and highly reliable results. A fast 15ms measurement speed effectively increases productivity when working in an automated environment.

In addition to the excellent measurement features found in Chroma’s other LCR Meters, the 11050 includes additional useful functions. It has 3 output impedance modes to satisfy demands of measuring and working with other instruments. The versatile digital display can be configured to best fit the current testing resolution and the test signal monitoring function displays the voltage and current that is actually carried to the DUT. The timing settings of trigger delay, measure delay and average number of times allow the measurements to transfer seamlessly to an automated test environment providing accurate results within a limited testing time.

- Partner Content -

A Dash of Maxwell’s: A Maxwell’s Equations Primer – Part One

Solving Maxwell’s Equations for real-life situations, like predicting the RF emissions from a cell tower, requires more mathematical horsepower than any individual mind can muster. These equations don’t give the scientist or engineer just insight, they are literally the answer to everything RF.

The Chroma 11050 adopts a detached design which provides several advantages. Since test processing and the display use separate CPUs, the testing speed is increased and shorter test leads are needed when integrated into an automated test environment. Shorter test leads improve the accuracy of high frequency measurements.

For more information and specs on Chroma’s 10MHz HF LCR Meter, visit http://www.chromausa.com/lcrmeters/11050-hf-lcr-meter.php.
