Agilent Technologies Introduces High-Sensitivity Multiport Optical Power Meters that Combine Highest Optical Performance and Large Data Storage in a Compact Platform

Agilent Technologies Inc. has introduced the latest addition to its extensive optical power-meter portfolio. The two- channel N7747A and four-channel N7748A bring the industry-leading sensitivity of the 81634B sensor module to the compact multichannel N77 platform, with updated memory size and data-transfer speed. The Agilent N7747A and N7748A optical power meters enable engineers to make parallel multiport measurements and monitor weak signals and small signal changes with high precision in, for example, communications or sensing applications. The meters can detect power levels down to -110 dBm and log data at intervals down to 25 µs with up to 1 million points per channel. An equally large data buffer supports simultaneous measurement and data transfer.

With these features and specifications, the meters make it easy for engineers to monitor signal stability and transient events for long periods. Up to eight power-meter channels fit in a single 19-inch rack-height unit. Each channel also has a front-panel BNC connector that delivers analog output voltage proportional to the measured signal.

- Partner Content -

A Dash of Maxwell’s: A Maxwell’s Equations Primer – Part One

Solving Maxwell’s Equations for real-life situations, like predicting the RF emissions from a cell tower, requires more mathematical horsepower than any individual mind can muster. These equations don’t give the scientist or engineer just insight, they are literally the answer to everything RF.

Like the faster N7744A and N7745A, these new power meters can be used with N77xx viewer software for simple control and reading and are programmable with the same set of SPCI commands as the rest of Agilent’s optical power-meter portfolio. The latest version of the popular 816x VXI plug&play driver also adds support for these products. Computer interfaces are provided for USB 2.0, LAN and GPIB.

In addition to high sensitivity, low noise and solid stability, the N7747A and N7748A also provide high relative accuracy like the 81634B modules, with extremely low polarization dependence and spectral ripple as well as specified linearity. This combines to make these power meters an excellent choice in setups for measuring insertion loss and lowest PDL in passive optical components.

Additional information about Agilent’s new high-sensitivity optical power meters is available at and
