Aeroflex Announces Full Bi-Directional Cat 6 LTE-A Mobile Handset Test Capability

Aeroflex Limited, a wholly owned subsidiary of Aeroflex Holding Corp., announced that the 7100 Digital Radio Test Set provides LTE-A carrier aggregation testing at full Cat 6 data rates of 300 Mbps downlink and 50 Mbps uplink simultaneously for LTE-A in FDD mode, and now also supports carrier aggregation in TDD mode.

The Cat 6 capability is available via an upgrade to the standard 7100 software and the use of a RF combiner, allowing users to maximize the potential of their existing test equipment investment.

The LTE-A capability of the 7100 facilitates testing to 3GPP Release 10 specifications on two non-contiguous component carriers, with both FDD and TDD modes supported, and with 2×2 downlink MIMO or SISO for each component carrier. All Release 10 RF band combinations are supported, including the downlink-only Band 29.

- Partner Content -

A Dash of Maxwell’s: A Maxwell’s Equations Primer – Part One

Solving Maxwell’s Equations for real-life situations, like predicting the RF emissions from a cell tower, requires more mathematical horsepower than any individual mind can muster. These equations don’t give the scientist or engineer just insight, they are literally the answer to everything RF.

Symmetrical bandwidths of 5+5 MHz, 10+10 MHz and 20+20 MHz are supported, along with asymmetrical bandwidth combinations that include 5 MHz, 10 MHz, 15 MHz, and 20 MHz.

Test capability—validated against the industry benchmark, the Aeroflex TM500 test mobile—includes 300Mbps DL and 50Mbps UL bi-directional data rates to Cat 6; full protocol stack; detailed logging; data connection and throughput performance test; and end-to-end throughput using IP connections. UDP, TCP IPv4/IPv6 are supported with multiple PDN connections, both with or without RoHC (robust header compression). Automated regression test is supported via API.

For more information, contact your local Aeroflex sales office by visiting or calling Aeroflex Sales at (800) 835-2352 [US], +44 (0)1438 742200 [UK] or info-test@aeroflex.com
