Advanced Pulse Analysis Software

Keysight softwareKeysight Technologies, Inc. announced comprehensive pulsed radar analysis software. The new 89600 VSA software’s pulse analysis option (BHQ) is used in radar and electronic counter measure applications for capturing and analyzing threats and jamming responses.

The software option gives R&D engineers the flexibility to define unique pulse characteristics and analyze them in the time and frequency domains. The software also provides tabular statistical reports summarizing the critical pulse parameters that are of interest to system designers.

Used in conjunction with the recently introduced UXA X-Series signal analyzer, designers can make pulse measurements up to 510 MHz analysis bandwidth – the widest RF analysis bandwidth available today. The analyzer also has excellent phase noise and dynamic range specifications.

- Partner Content -

VSWR and its Effects on Power Amplifiers

Voltage Standing Wave Ratio results from an impedance mismatch between a source (an amplifier) and a load (test application). This mismatch can influence the performance of the source.

For designers using the Infiniium oscilloscopes or the M9703A wideband digitizer to achieve even wider bandwidths, a new segmented memory capture feature can reduce memory consumption. By recording only pulses, with minimal recording of off-pulse time, segmented memory capture makes a longer recording period possible. This means that these instruments can now gather a greater amount of data, allowing designers to characterize complex pulse signals with more confidence than ever before.

More information about Keysight’s software is available www.keysight.com/find/software.
