A Brief History of Electrostatic Discharge Testing of Electronic Products

1403 esd-testing cover

1403 esd-testing coverWith the inventions of the transistor in 1948 and the Integrated Circuit in 1958, and the utilization of these major breakthroughs in the development of computers and other electronic devices, industry began to worry about and to design components and end-products that could survive the discharge of electrostatic discharges to chips, printed circuit boards, and final packaged-products.

The 1960s and 1970s saw individual companies developing their own test values and test techniques. The international standards organizations got involved in the 1980s with the release of IEC 801-2 on ESD limits and test methods. Since the 1980s, most companies test their end-products for ESD immunity to IEC 801-2 and its follow-on standard, IEC 61000-4-2.


In the Beginning

- Partner Content -

Why Capacitance? Benefits & Applications of Digital Capacitive Solutions

In this paper, readers will discover digital capacitive displacement measurement solutions not possible with conventional analog systems. The following applications address a wide range of industry sectors. Each example demonstrates how digital capacitive sensing systems rival the performance of more expensive and complex measurement systems at a fraction of the cost

Electrostatic discharge (ESD) phenomena have been known since the Greek civilization was dominant thousands of years ago. People in cold climates were very familiar with the ESD effect in a low-relative humidity environment as was frequently experienced in indoor environments in the winter time.

As electronic components changed from electronic tubes to solid state electronics in the 1950s, companies became concerned with damage to electronic components and interruption of normal operation of electronic equipment. This article is primarily addressing the interruption effects of ESD to packaged electronic equipment.

The 1960s and 1970s

Most electronic companies in the 1960s and 1970s were aware of and concerned with ESD. The companies tended to have proprietary standards and test methods on ESD and were not interested in exchanging information with their competitors on ESD.

The Human Body Discharge model was commonly used by the companies to test products with an ESD tester. The capacitance of a human being was estimated to be in the 100 to 250 picofarad range depending on the size of the person and the length and shape of the human’s shoes. A common discharge value for early standards was 5000 volts. The discharge resistance was often taken as 500 ohms; the resistance of the human finger. The discharge was an ‘air-gap’ discharge which closely simulated the actual ESD phenomena.

- From Our Sponsors -

There were some companies that were using a contact discharge approach to ESD where the ESD tester was in physical (metal to metal) contact with the electronic equipment. The contact discharge was a more repeatable event than the air discharge method.

The common joke among EMC consultants in the 1970s was on the magnitude of the ESD discharge. In most cases, the companies started at a recommended 5 kilovolts amplitude; when the companies products could all pass that level, the consultants would recommend 7500 volts amplitude and so on!

Horizontal Coupling Plane (HCP)

The development of the HCP started with a well-known cash-register company in the 1970s. At that time, they had an air-discharge ESD gun which was used for their product development testing. The EMC engineers very-cleverly developed an all-plastic cash register and the ESD gun would not discharge to the cash register, and, therefore, by definition the product passed the ESD test.

The all-plastic cash register went into production and out into the real-world with real customers. One of the first buyers of the all-plastic cash register was a fast-food restaurant that used an all-metal counter top to separate the customers from the employee/kitchen area. When winter came, the customers would enter the restaurant, discharge an ESD event to the metal counter-top and the all-plastic cash register’s cash drawer would immediately open. The fast-food restaurant company was not pleased and returned the all-plastic cash registers to the manufacturer.

The EMC Engineers went back to work; they placed a metal ground plane under the all-plastic cash register and discharged to the metal ground plane (now known as the HCP) to simulate the real-life experience. They eventually came up with design fixes that allowed the all-plastic register to pass the ESD test. While they were developing the HCP, they realized the HCP could be turned on its side to represent a vertical metal file cabinet and they proceeded to design the cash register to pass that test also (that HCP on its side is the present-day Vertical Coupling Plane (VCP) test.


Kangaroo Leather

One computer company in the 1970s began experimenting with ESD relative to its computers and computer peripherals. A Van de Graaf generator, some high-voltage sources, and a green nylon carpet were all tried as potential ESD generators. It was decided to go with the standard green nylon carpet to begin with. A number of volunteers were organized and asked to shuffle their feet on the carpet (in a controlled humidity environment) while holding on to a scientific electrostatic voltmeter. Again, in most cases, at relative humidity-levels of 10% and greater, about 5 to 7 kilovolts was the maximum value measured on the human subjects.

One product made by the computer company had a wide distribution in Australia and it had ESD problems whereas deliveries to other countries had no ESD problems. An engineer from the company who worked with the Australian customers, visited the EMC lab and discussed the issue with the EMC lab engineers. The engineers took the Australian engineer into the controlled environment and asked him to shuffle his feet while connected to the electrostatic voltmeter. Much to the EMC lab’s surprise, the voltmeter registered 18000 volts! After some discussions with the Australian native, it was discerned that he had normal clothing on his body with the exception of his shoes which were made of kangaroo leather. Needless to say, the lab made that fact known while in parallel it developed an engineering fix to its product to allow it to pass 18 Kilovolts.


1980s

The 1980s saw the release of the IBM-Personal Computer in 1981 which legitimized the PC market and it saw a movement of the computer industry and similar electronic industries (medical equipment, laboratory equipment, etc.) to international standards on Electrostatic Discharge.

The first edition of International Electrotechnical Commission (IEC) Publication 801-2 was released in 1984. It was titled Electromagnetic Compatibility for Industrial-Process Measurement and Control Equipment – Part 2: Electrostatic Discharge Requirements.

The standard carefully pointed out in a NOTE that: From the technical point of view, the more precise term for this phenomenon would be static electricity discharge. However, the term electrostatic discharge (ESD) is widely used in the technical world and in technical literature. Therefore, it has been decided to retain the term ESD in the title.

The characteristics of the ESD generator in the 1984 edition were: Energy Storage Capacitor – 150 pF +/- 10%, discharge resistor – 150 ohms +/- 5%, and an output voltage of 2 kV to 16.5 kV. The output voltage was a positive voltage only!

The rise-time of the discharge current was 5 ns +/- 30% at 4 kV and the pulse width was approximately 30 ns +/- 30%.

The test was an air-discharge test.

The 1984 edition did have a requirement for discharging to the earth reference plane to simulate discharges to objects in the vicinity of the Equipment Under Test (EUT).

See Figure 5 of IEC 801-2 for the 1984 illustration of the test set-up for table-top-mounted equipment, laboratory tests (Figure 1). Note that there is no ground reference plane on the floor, the earth reference plane is on top of the table and it is grounded to a mains terminal (earth connection) via a cable. The insulating support between the EUT and the earth reference plane is 10 cm thick.

1403 F21 fig1

Figure 1


Second Edition of IEC 801-2 – 1991

The second edition of IEC 801-2 was released in 1991.

One of the major changes in the standard was that the contact discharge was the preferred test method not the air discharge method.

The energy storage capacitor remained at 150 pF but the discharge changed to 330 ohms plus or minus 10%. The output voltage was up to 8 kVolts for contact discharge and 15 kVolts for air discharge; both positive and negative. The rise-time at 4 kilovolts had decreased to 0.7 to 1 nanosecond. The values of the parameters of the discharge current had to be verified with a 1 GHz oscilloscope. The grounding cable from the VCP and the HCP to the ground reference plane had 470 kohm resistors located at each end of the cable.


First Edition of IEC 1000-4-2

The follow-on standard to IEC 801-2 (released in 1995) was IEC 1000-4-2 – International Standard on EMC – Part 4: Testing and Measurement Techniques – Section 2: Electrostatic Discharge Immunity Test – Basic EMC Publication.

Note – The Europeans put a 6 in front of the 1000-4-2 and the International Community followed suit in the 1996 timeframe. So, all the IEC 1000 series standards became IEC 61000 series.

The parameter of the ESD Generator stayed constant from the 1991 – 801-2 standard; that is, the energy storage capacitor was 150 pF, the discharge resistance was 330 ohms, and the output voltage of 8 kV for contact discharge and 15 kV for air discharge. The polarity of the output voltages was both positive and negative.

See Figure 5 (Example of Test Set-up for table-top equipment, laboratory tests) from the 1995 version of IEC 1000-4-2 (Figure 2). The 1995 version shows a much larger horizontal coupling plane than the 1984 standard, a vertical coupling plane (unmentioned in 1984), a ground reference plane on the floor, and grounding cables between the horizontal coupling plane and vertical coupling plane and the ground reference plane (with 470 kohm resistors on both ends of the grounding cables.) Note that the insulating support between the EUT and the Horizontal Coupling Plane is only 0.5 mm thick (reduced from 100 mm thick in the 1984 edition.)

1403 F21 fig2

Figure 2


Second Edition of IEC 61000-4-2

The second edition of IEC 61000-4-2 was released in 2008 and it cancelled and replaced the first edition published in 1995, its Amendment 1 (1998) and its Amendment 2 (2000).

The key parameters of the ESD Generator remained constant at 150 pF for the energy storage capacitor and the discharge resistance is 330 ohms. The output voltage for contact discharge remained constant at a highest value of 8 kilovolts and the air discharge at 15 kilovolts. The amplitudes were quoted in both the negative and positive polarities.

Summary

Electrostatic discharge testing has evolved from a company-based reliability test in the 1960s and 1970s to a performance test on electronic products in the 2013 timeframe. The requirement is for electronic products to operate successfully when subjected to ESD phenomena representing the real-world environment as simulated in an EMC laboratory. The emphasis has switched from the susceptibility of equipment to quoting how immune a product is to air-discharge and contact discharges from a portable ESD tester whose output is compliant with the latest international standard criteria. favicon

Note
The author thanks the International Electrotechnical Commission (IEC) for permission to reproduce Information from its International Standards IEC 60801-2 ed.1.0 (1984) and IEC 60801-2 ed.2.0 (1991). All such extracts are copyright of IEC, Geneva, Switzerland. All rights reserved. Further information on the IEC is available from www.iec.ch. IEC has no responsibility for the placement and context in which the extracts and contents are reproduced by the author, nor is IEC in any way responsible for the other content or accuracy therein.



author_hoolian-dan Daniel D. Hoolihan
is the Founder and Principal of Hoolihan EMC Consulting. He is Chair of the ANSI-ASC C63 Committee on EMC. He is a Past-President of the EMC Society of the IEEE and is presently serving on the Board of Directors. He is presently an assessor for the NIST NVLAP EMC and Telecom Lab Accreditation program. For further information, contact Dan at danhoolihanemc@aol.com or 651-213-0966.
