Teseq adds 8-channel Arbitrary Waveform Generator to Transient System for All-in-One Automotive Immunity Testing

Teseq PRTeseq introduces an eight-channel arbitrary waveform generator for automotive testing.  The ARB 5500 fits inside the transient generator and features memory for over 64,000 standard waveform segments as well as 1 GB of Clone memory for user-defined shapes.  This is enough memory for several thousand hours of simulations.

Now available in new systems or as an upgrade for existing NSG 5500 units, the ARB 5500 provides the necessary control for all battery simulation tests and advanced functions like power magnetics and continuous wave (ripple) simulations.

Teseq’s ARB 5500 supports waveforms that may be difficult to describe and real-world events that need to be simulated. All vital waveforms can be created from the built-in wave shapes or by loading a Clone™, a memory map of user-identified or prerecorded wave shapes, from an external application.

- Partner Content -

A Dash of Maxwell’s: A Maxwell’s Equations Primer – Part Two

Maxwell’s Equations are eloquently simple yet excruciatingly complex. Their first statement by James Clerk Maxwell in 1864 heralded the beginning of the age of radio and, one could argue, the age of modern electronics.

In addition to individual trigger outputs and programmable current limits, each of the ARB 5500’s eight channels support 16-bit output with a 10 MS/s playback for true stepless operation.  The channels can be perfectly synchronized with an advanced parameter-ramping function when paired with Teseq’s redesigned AutoStar 7 software.  This intuitive software offers drag and drop programming and what you see is what you get operation.  All channels are individually calibrated with values stored right on the ARB 5500.

Every segment in the new arbitrary waveform generator features its own trigger, advanced rectification, phase angle and duty cycle programming to effortlessly meet even the most complex standards’ requirements.

The ARB 5500 has an output voltage range of -10 V to +10 V, a frequency range up to 500 kHz with isolated output.  With the addition of transient modules and a new dropout switch, nearly all automotive tests can be performed using a single 19″ generator.

Technical Specifications

  • Perfectly synchronized, eight-channel ARB built into the transient generator
  • Memory for over 64,000 segments
  • 16-bit, stepless operation
  • 1 GB of Clone memory for user-defined waveforms
  • Output voltage range of -10 V to +10 V
  • Frequency range up to 500 KHz

For more information, please visit http://www.teseq.com.
