2 MHz Transformer Driver for Isolated Power Supplies

Photo Source: Richardson RFPD
Photo Source: Richardson RFPD

Richardson RFPD, Inc. has announced the availability and full design support capabilities for a new transformer driver from Peregrine Semiconductor Corporation.

The PE22100 is a push-pull driver for small transformers in isolated power supply applications. The new device drives the primary of a center-tapped transformer from a 3.0 V or 5 V supply to deliver an isolated power supply.

The driver consists of an on-chip oscillator with frequency set by an external capacitor. The oscillator output is divided-by-two in frequency to create anti-phase clock signals that drive two power switches. The device also contains an internal current limit and thermal cutout.

- Partner Content -

VSWR and its Effects on Power Amplifiers

Voltage Standing Wave Ratio results from an impedance mismatch between a source (an amplifier) and a load (test application). This mismatch can influence the performance of the source.

It is designed for isolated power supply applications, including isolated data acquisition, industrial automation and instrumentation, isolated gate drivers and medical equipment.

Source: Richardson RFPD, Inc.
